Lumina® By FDC® 2407 Premium Flexible Engineering-Grade Reflective Film

Lumina® By FDC® 2407 Premium Flexible Engineering-Grade Reflective Film
Company Page Click Here
Lumina® by FDC 2407 is a glass-beaded, retro-reflective vinyl film that renders excellent reflectivity at night. This series is for fleet and vehicle markings where riveted and corrugated surfaces may be required. 2407 is highly resistant to the extremes of hot, cold, dry, and humid conditions.

2407 Series | Lumina Premium Engineer Grade Reflective Film
Lumina series 2407 is a premium engineer grade reflective film designed for producing permanent signage, Graphics and decals requiring long-term durability. This product meets ASTM D 4956 Type I standards for reflectivity. To order punched material, use part number 2457.

Film Technology | Retroreflective
Film Thickness | 5.9 mil
Color | 11 colors – see color chart
Outdoor Durability | 7 Years
Finish | Gloss
Blockout | Yes
Adhesive | Permanent / Clear - Acrylic
Liner | 90# (Lay Flat)
Conformability | Simple curves, rivets, corrugations, and flat surfaces
Shelf Life | 1 Year
CUTTING
Computer Cut | Yes
Steel Rule | Yes
Thermal Die | Yes
Flat Bed | Yes
Sheetable | Yes
Laminate | Yes / Cold
PRINTING
Thermal Transfer | Yes
Solvent | No
Eco-Solvent | No
Latex | No
UV | No
Screen | Yes
INSTALLATION
Wet Apply | No
Min. App. Temp. | 60°F
Interior / Exterior | Yes
FILM
• Film Thickness:(mils/?m)5.7 / 158 (+/- 10%)
• Gloss: (60°) >87
• Opacity: (%) 98 (average - varies by color)
• Tensile Strength: (lbs/in) 26.4 N/25mm width
• Elongation: (%) MD > 200 / CD > 200
• Dimensional Stability: (FTM 14) 169%
ADHESIVE
• Adhesive Type: Emulsion Acrylic
• Adhesive Thickness: (mils/?m) N/A
• Adhesive Color: Clear
• Peel Strength on Aluminum: (lbs/in) / 0.2mm Overlap: 19.2mm
• Peel Strength on Stainless Steel: (lbs/in) / N/A
LINER
• Liner Weight: (#/gsm) 90 / 127
• Liner Type: White Clay Coated Kraft
• Liner Thickness: (mils/?m) N/A
• Release Force: N/A
PERFORMANCE GUIDANCE
• Min. Application Temp. :flat/smooth surface 59 °F
• Service Temp.: -22 °F to 176 °F
• Shelf Life: up to 1 year
• Storage Temp. / Rel. Humidity: 70 °F / 50%
• Outdoor Durability: up to 7 years
